PP-NESC10AU - 10A ESC
(Brushless Electronic Speed Controller)

Specifications

Features

• Soft Starting – Reduces the stress on the airframe.
• ESC comes with 3 male and 3 female connectors, so no more hunting around for connectors to get your new project in the air.
• Auto Timing – no need for manual selection.
• Self Checking
• Low Voltage Cut Off – Protect your batteries from damage due to excessive drain.
• Thermally Protected – The ESC will reduce the output power to the motor depending upon its temperature.
• Signal lost Protection – Upon loss of radio signal the ESC will stop the motor.
• Power on Protection – The motor will not start unless the throttle stick is in the off position when the power is applied.
• Simple Parameter Setting via the transmitter

Programmable Parameters

• Low voltage threshold: User can set the low voltage threshold according to cell count. The range is 2.65V, 2.85V and 3.1V, the default is 2.85 Volts per LiPo cell.
• Brake: Options are "On" or "Off". The default setting is “off”. We recommend that the brake is set to off unless a folding prop is used.
• Timing: Options are Low, Medium or High. The default setting is low. We recommend medium or High timing for all outrunners.
• Throttle Response: The time taken for the ESC to go from zero to full throttle. 0.25 ~ 4.00 seconds. The default is 0.25 seconds.
• Cut Off: Reduce power, or hard cut off. The default setting is reduce power.
• Start power: To set the ratio of output power when starting in range of 0% - 45%. The default setting is 0%.
• Governor mode: On or Off. The default is Off.
• Rotational direction: The direction of rotation can be changed by swapping any 2 of the 3 wires that connect to the motor.
