Bit Secure ShoppingPP-EESC30AU
- 30A ESC
|
|
|
|
Specifications
| Constant Current | 30A |
| Burst Current | 40A for 10 Seconds |
| Motor Input Voltage Range | 2-4 LiPo (5.6 - 16.8V DC) |
| BEC Voltage Range | 2-4 LiPo (5.6 - 12.6V DC) |
| BEC Output | 5V DC @ 2A (3-4 mini servos) |
| Weight (g) | 25g |
| Size (mm) | 48mm x 25mm x 11mm |
| Connectors Supplied | 3x 3.5mm Male, 3x 3.5mm Female + Heatshrink |
Please click here
for a video demo of
its soft starting
and linear throttlingFeatures
-
Very Soft Starting – Reduces the stress on the airframe.
-
ESC comes with 3 male and 3 female connectors, so no more hunting around for connectors to get your new project in the air.
-
Linear Throttle Response – Smooth and progressive throttling over the whole stick movement – easier to fly.
-
Auto Timing – no need for manual selection.
-
Low Voltage Cut Off – Protect your batteries from damage due to excessive drain.
-
Thermally Protected – The ESC will reduce the output power to the motor depending upon its temperature.
-
Signal lost Protection – Upon loss of radio signal the ESC will reduce the output power to 20% for three second and then stop the motor.
-
Loss of a Phase Protection – The ESC will stop the motor. The throttle stick has to be returned to the off position for 1 second before the motor will restart.
-
Object Striking Protection – The ESC will stop the motor. The throttle stick has to be returned to the off position for 1 second before the motor will restart.
-
Power on Protection – The motor will not start unless the throttle stick is in the off position when the power is applied.
-
The ESC's come pre-programmed with soft start, brake off and medium timing which is suitable for nearly all inrunners and outrunners
-
Simple Parameter Setting.
Programmable Parameters
-
Throttle Range – suitable for all transmitters on the market.
-
Low Voltage Protection – Highest / Higher / Lower / Lowest. The default is "Lower".
-
For Li-XX, Voltage for each cell is 3.25V / 3.0V / 2.75V / 2.5V. The default is "2.75V" per cell
-
For Ni-XX, Voltages are 70% / 65% / 60% / 55%. The default is "60%" of the voltage on connection
-
-
Battery Type - Li-XX / Ni-XX. The default is "Li-XX".
-
Flying Mode - Mode 1 / Mode 2 / Mode 3. The default is "Mode 2". Mode 1 is more efficient but less power. Mode 3 (hard/high timing) is less efficient but more power. Mode 2 (medium timing) gives good efficiency and good power. Outrunners should only be used on either Mode 2 or Mode 3.
-
Brake Setting – Enable brake or disable brake. The default is "brake disabled".
If
the motor spins backwards,
swap any two of the
three wires that go
from the ESC to the
motor, it's as simple
as that.
User Instructions
 |
30A ESC User Instructions (PP-EESC) |
|
Programming Card User Instructions for PP-EESC ESC's |
